Sony TA-FE320R TA-FE520R Integrated Stereo Amplifier Service Manual

PDF version of the Service Manual for Sony TA-FE320R TA-FE520R Integrated Stereo Amplifier . It is a complete scan with all information that was in the original repair manual.

Multi-Page circuit diagrams have been scanned in such a way that if you print this you can line up the pages easily.  Service manuals normally include details of the printed circuit boards, block diagrams and assembly instructions.  If you are looking to repair a Sony TA-FE320R TA-FE520R Integrated Stereo Amplifier then this is an invaluable source of information.

Note that this is NOT the owners manual but a scan of the original service manual to help diagnose faults with a Sony TA-FE320R TA-FE520R Integrated Stereo Amplifier

This service manual has 26 pages and is in English.
